Luminey MonaWall 5KW IP65 Lithium Battery

Luminey MonaWall-SE5 – 5kWh Wall-Mounted Lithium Battery Detailed Technical Specifications General Overview Brand: Luminey Model: MonaWall-SE5 Battery Type: LiFePO₄ (Lithium Iron Phosphate) System Type: Wall-Mounted Energy Storage Battery Application: Residential (Indoor & Outdoor) Energy & Capacity Nominal Energy: 5 kWh Usable Energy: 5 kWh (100% DoD supported) Nominal Voltage: 51.2 V Voltage Range (Cut-off): 44.8 – 55.2 V Performance & Current Rated Charge/Discharge Current: 50 A / 50 A (0.5C) Max Continuous Current: 100 A / 100 A (1C) Roundtrip Efficiency: >98% 🔁 Cycle Life & Durability Cycle Life: ≥6000 cycles Design Life: Long-term residential usage Depth of Discharge (DoD): 100% (full utilization) Smart Features Built-in WiFi: Yes Mobile App Monitoring: Yes (remote control & tracking) Built-in Heater: Yes (better cold performance) Plug & Play Terminals: Quick DC connection system Scalability Parallel Support: Up to 16 units Max System Capacity: 80 kWh Communication Interfaces: CAN 2.0 RS485 Safety & Design Anti-expansion design Advanced BMS protection High thermal stability (LFP chemistry) Strong enclosure for durability Operating Conditions Installation: Indoor / Outdoor Charging Temperature: -10°C to +50°C Discharging Temperature: -20°C to +50°C Humidity: 10% – 95% (non-condensing) Altitude: <4000 m Physical Specifications Dimensions (W × H × D): 544 × 524 × 162 mm Weight: 55 kg Cooling & Protection Cooling Method: Natural convection Ingress Protection: IP65 (water & dust resistant) Certifications IEC62619 CE UN38.3
